Limestone Grinder

Home » Products » Limestone Grinder










Construction: Heavy gauge Mild Steel, Painted Finish
General Dimension: 2 m x 1.2mx 1.082 m (LxWxH)
End plate: 19mm Thk
Casing: 16 mm thk.
Hopper : 6 mm thk.
Breaker plate: 19 mm Thk
Flanges: 9mm thk.
Flange of split casing: 38mm x 38 mm Square Bar.
Fixed Screen:   Flat bar 6mm t mounted on 9mm thk flange.
Rotor Assy.: 12 mm thk Circular rotor mounted on 150mm Ø  Spindle shaft  mounted on Plummer block bearing with Blade, Pin & spacer.
Blade: 3/4" thk SAE 4140
Bearing :  Plummer Block  SKF or NSK Brand.
Motor base: 10 mm thk.
*depends on clients' specifications
